This 30 ton Extreme log splitter is manufactured and American built .
This wood splitter is Ram Splitters flag ship model and is built commercial tough. The average cycle time on this unit is 10-12 seconds due to its 22GPM pump size. This gas log splitter will spit in the horizontal position and comes with log lifting arm.
This log splitter also comes with double handled control valve locks. This means you can do a complete cycle (split) automatically by doing a full extend and retract on it's own! This machine comes standard with larger tires, 4 way splitting wedge, Hour Meter, Automatic Dual valve, front wheel stand, and hydraulic log lifter.
Features
- Beam Structure: 3" wide x 6" tall - 6" Top Plate Tubular Design
- Splitting Wedge: 12" High
- Operating Position: Horizontial with Lift
- Force / Tonnage: 30 Ton (Up to 60,000 lbs)
Specifications
| Beam Structure |
3" wide x 6" tall - 6" Top Plate Tubular Design |
| Splitting Wedge |
12" High |
| Operating Position |
Horizontal with Lift |
| Force / Tonnage |
30 Ton (Up to 60,000 lbs) |
| Cylinder |
5" x 24" 2" Rod |
| Cycle Time |
10-12 Seconds (Approx) |
| Log Opening |
26 Inches |
| Wheels & Tires |
High-Speed, 4 ply 12" |
| Road Towable |
Yes - Tow package included |
| Motor |
Subaru EX 14 HP or Honda GX 13 HP |
| Operating Size |
50" wide and 84" long |
| Hydraulic System |
14 Gallon Tank + Cylinder, and Hoses |
| Safety Control Valve |
Double Handle Dual Locking |
| 2 Stage Pump |
22 Gallons Per Minute |
| Operation Weight |
850 LBS |
| Made in USA |
Yes! |
| Working Height |
22" |
| Log Cradles |
Included other side of lift |
| 4 Way Wedge |
Included |
| Electric Start |
Included |
What Our Experts Think
-
Powerful 30-ton gas-powered ram log splitter, ideal for heavy-duty splitting.
-
Includes an integrated log lift for easier handling of large, heavy logs.
-
Durable steel construction designed for long-lasting performance.
-
Perfect for farmers, landscapers, and firewood producers handling high volumes.
-
Compact design allows use in both residential and professional settings.
Q&A
Q: What is the splitting force of this ram splitter?
A: It provides 30 tons of splitting force, handling large and dense logs.
Q: What powers this splitter?
A: It’s gas-powered, giving mobility and high performance without relying on external power.
Q: Does it include a log lift?
A: Yes, the built-in lift makes loading heavy logs safer and easier.
Q: Who is this ideal for?
A: Suitable for farmers, landscapers, and firewood producers needing high-volume efficiency.
Q: Is it suitable for residential use?
A: Yes, but it’s designed for serious heavy-duty applications.
Maintenance Tips
-
Check and maintain the engine oil and fuel system regularly.
-
Inspect hydraulic hoses and fittings before each use.
-
Lubricate moving parts to prevent wear.
-
Keep the splitter clean and free of debris.
-
Store in a dry, sheltered area to prevent rust and damage.
