MANUAL PUSH AND PULL, POWERED LIFTING AND LOWERING
- 1,500-watt lift motor.
- Special chain steering system.
- Easy operation for lifting and lowering.
- Strong battery with 12V/120AH capacity and over charge design.
- Adjustable forks & fix legs.
DIMENSIONS:
- Overall Length：68.7"
- Overall Width: 37.8''
- Recommended Aisle Width：90"
- Turning Radius: 56"
- Mast Height Lowered: 82.7''
- Mast Height Raised: 140.3''
- Load Center: 15.7"
- Wheel Diameter : 7''/3.15''
FORKS:
- Fork height, Lowered: 3.5''
- Thickness: 2.3''
- Width: 5.6''
- Length: 42''
- Adjustable fork width 11.8-36.6''
Features:
- Foot pedal brake for safety and ramp usage.
- Equipped with explosion-proof valve, against of sudden drop of forks and prevent operator from harm.
- With hydraulic leveler control lifting and lowering, speed is adjustable.
SPEED:
- Lifting speed(laden/unladen) : 2/3.2mph
- Lowering speed(laden/unladen) : 3.9/3.5mph
Specifications
- Not explosion proof.
- This stacker is designed to be used on flat ground, avoiding uneven grounds with potholes or large ramp.
- Normal Ambient temperature shall not be higher than +104°F and no lower than -13°F.
- Fully charge battery before use to avoid damaging cells.
- Charger plugs into standard 110V-120V outlets.
- Charge the truck once a month even it's not in use.
Videos
Manuals
What Our Experts Think
-
High lifting capacity – Handles loads up to 3,300 lbs with ease.
-
118-inch lifting height – Ideal for stacking and material handling in warehouses.
-
Power lift system – Reduces operator effort and increases productivity.
-
Robust construction – Built for durability in industrial environments.
Q&A
Q: Is this stacker suitable for heavy-duty warehouse use?
A: Yes, designed for lifting heavy loads efficiently.
Q: Can it reach high shelving?
A: Yes, with a max lift height of 118 inches.
Maintenance Tips
-
Regularly check hydraulic fluid levels.
-
Inspect forks and mast for wear or damage.
-
Lubricate moving parts as needed.
-
Schedule professional inspections periodically.
