BevLes - PICA70-32-AED-1R3, BevLes Full Size Extra Deep Non-Insulated PICA Proofing Cabinet, 115V, Right Hand Hinge, 3 Doors, in Silver - PICA70-32-AED-1R3
Essential for commercial bakeries, the BevLes Full Size Extra Deep Non-Insulated PICA Proofing Cabinet provides the ideal environment to facilitate the proofing process for yeast-raised dough. Designed to maintain a consistent temperature and humidity level, this proofing cabinet is constructed of durable aluminum. This full-size AED model is extra deep at 39" to accommodate pans and screens. The clear Lexan doors with heavy-duty right hand hinges let you easily see what’s inside without opening the door. User-friendly, bottom-mounted controls feature independent heat and humidity adjustment. Temperature ranges from 60° to 120°F (16° to 49°C) while the water reservoir holds up to 5 quarts (4.7 liters). Our BevLes "cast-in" humidity system prevents element burnout while providing added safety for the operator. This BevLes proofing cabinet has a self-draining feature for excess moisture collection below the cabinet. The unit is equipped with heavy-duty plate swivel casters with 5" (127mm) neoprene wheels, two with locks, for easy mobility. BevLes extra deep proofing cabinets are available in insulated and non-insulated models with right- or left-hand hinges. Ideal for everything from donuts to cinnamon rolls, the BevLes Full Size Extra Deep Non-Insulated PICA Proofing Cabinet lets you proof dough to perfection.
Features
- This full size extra deep non-insulated proofing cabinet is ideal for maintaining a consistent temperature and humidity level during the proofing process
- Features all aluminum construction
- Full size AED models are extra deep at 39" to accommodate pans and screens
- Clear Lexan doors with heavy-duty right hand hinges and positive closing latches with full perimeter gaskets
- User-friendly, bottom mounted controls feature independent heat and humidity adjustment
- Temperature range from 60° to 120°F (16° to 49°C) while the water reservoir holds up to 5 quarts (4.7 liters)
- BevLes "cast-in" humidity system prevents element burnout while providing added safety for the operator
- Self-draining feature for excess moisture collection below the cabinet
- Equipped with heavy duty plate swivel casters with 5" (127mm)Â neoprene wheels, two with locks
- Non-insulated proofing cabinets are available in full, 3/4, half and undercounter size models
- Covered by the BevLes One-Year Limited Warranty
Specifications
| Adjustable Shelves |
Yes |
| Adjustable Temperature Control |
Yes |
| Amperage |
15 |
| Assembled Dimensions (LxWxH) |
39" x 29" x 71.50" |
| Assembled Weight |
280 lbs. |
| Assembly Required |
No |
| Capacity |
32 |
| Casters |
Yes |
| Color |
Silver |
| Cord Length |
96" |
| Cutout Depth (Front to Back) |
23" |
| Cutout Width (Side to Side) |
55" |
| Depth - Door Open 90° |
65" |
| Depth - Excluding Door |
39" |
| Depth - Excluding Handles |
39" |
| Door Color/Finish |
Silver |
| Door Material |
Lexan |
| Door Swing Orientation |
Left |
| Electric |
Yes |
| Height - Excluding Top Hinge |
71.50" |
| Installation Type |
Freestanding |
| Integrated Lock |
No |
| Interior Dimensions (D x W x H) |
32.5" x 23" x 55" |
| Material |
Aluminum |
| Number of Doors |
3 |
| Number of Shelves |
32 |
| Outdoor Use |
No |
| Plug Type |
5-15P |
| Temperature Range |
60° – 120° |
| Timer |
No |
| Use & Care Instructions |
Please reference Manual |
| Voltage |
115V |
| Warranty |
1 year |
| Case Pack Dimensions |
44" x 35" x 82" |
| Case Pack Weight |
290 lbs. |
| Case Quantity |
1 |
| Country of Origin |
USA |
| Freight Class |
150 |
| Usually Ships In |
2 – 4 days |
| Number of Boxes |
1 |
| Packaging Type |
Brown Box |
| Ship Type |
LTL |
| Shipped Assembled? |
Yes |
| Tariff Code (HTS) |
8417.20.0000 |
| ADA Compliant |
Yes |
| BPA Free |
Yes |
| Certifications |
ADA Compliant, cUL Listed |
| cETL Listed |
No |
| Energy Star |
No |
| ETL Listed |
No |
What our Experts Think
-
Extra-Deep Full-Size Storage – Accommodates larger pan capacities, ideal for bakeries and high-volume kitchens.
-
Three-Door Design – Improves workflow by allowing partial access while maintaining internal conditions.
-
115V Power – Easy plug-in setup with standard commercial outlets.
-
Right-Hand Hinge – Configured for layouts requiring right-side access for smoother kitchen flow.
-
Non-Insulated Build – Lightweight, economical, and easy to position in flexible workspaces.
Q&A
Q: What is the BevLes PICA70-32-AED-1R3 used for?
A: It’s a full-size extra deep non-insulated proofing cabinet built to maintain consistent humidity and temperature for dough proofing or holding hot food before service.
Q: How many pans can it hold?
A: This unit accommodates up to 32 full-size sheet pans, offering maximum storage capacity.
Q: What type of doors does it feature?
A: It comes with three right-hand hinged doors, allowing convenient access while keeping heat and humidity stable.
Q: What voltage does it require?
A: The PICA70-32-AED-1R3 runs on 115V, compatible with standard commercial kitchen power connections.
Q: Where is this cabinet commonly used?
A: Perfect for bakeries, restaurants, catering operations, and institutional kitchens requiring large-scale proofing and food holding.
Maintenance Tips
-
Wipe interior, exterior, and all three doors daily with mild soap and warm water to prevent buildup.
-
Avoid abrasive cleaners or pads to protect the stainless steel finish.
-
Inspect right-hand door gaskets regularly for wear and replace if needed for a proper seal.
-
Check heating elements and fans monthly to ensure consistent proofing performance.
-
Always disconnect power before cleaning or performing maintenance for safety.
