| Item Model Number |
LPT33 |
| Capacity |
3,300 lbs. @ 24" load center |
| Power |
24V Electric with Transistor Controller |
| Max Lift Height |
7.75" |
| Collapsed Height |
3.25" |
| Turning Radius |
52.5" |
| Travel Speed |
2.9 mph (empty), 2.7 mph (loaded) |
| Battery Type |
Easy Exchange Li-Ion Battery |
| Battery Capacity |
24V 20AH rechargeable |
| Charger |
110V plug-in internal |
| Tires/Wheels |
Drive: (1) 8.3" x 2.8" Polyurethane |
| Load: (2) 2.9" x 3.5" Polyurethane |
|
| Brakes |
Electromechanical Brake |
| Overall Fork Dimensions |
46" x 27" |
| Individual Fork Dimensions |
45" x 6" x 3.2" |
| Vehicle Dimensions |
60" x 27" x 47" |
| Weight (with Battery) |
375 lbs |
| Package Contents |
Big Joe LPT33 Lithium Pallet Truck |
| User Manual |
|
What Our Experts Think
-
3300 lbs Capacity – Perfect for handling medium to heavy loads with ease, making it ideal for a wide range of industrial and warehouse tasks.
-
Fully Electric Operation – Provides smooth and efficient lifting and travel with minimal effort, reducing operator strain and enhancing productivity.
-
Lithium Battery Technology – Faster charging times and longer operational life, ensuring consistent power and reduced downtime.
-
Compact & Maneuverable – Designed for tight spaces, allowing easy navigation around busy aisles and work areas.
-
New Condition – Ready to deliver reliable performance, built for long-lasting durability in demanding environments.
Q&A
Q: What is the maximum weight capacity of the Big Joe LPT33 Lithium Pallet Truck?
A: The LPT33 has a maximum weight capacity of 3,300 lbs, making it perfect for handling heavy pallets and loads in various environments.
Q: How is the LPT33 powered?
A: The LPT33 is powered by a lithium-ion battery, offering efficient, long-lasting power with a quicker recharge time than traditional batteries.
Q: What are the benefits of using a lithium pallet truck?
A: Lithium pallet trucks like the LPT33 provide faster charging, longer battery life, and require less maintenance compared to lead-acid battery trucks.
Q: Is the Big Joe LPT33 suitable for narrow aisles?
A: Yes, its compact design makes it ideal for maneuvering in narrow aisles and tight spaces, offering flexibility in busy warehouses.
Q: Is it easy to operate?
A: Yes, the Big Joe LPT33 features simple, intuitive controls that allow operators to lift, lower, and move pallets with ease.
Q: What materials are used in the construction of the LPT33?
A: The LPT33 is built with durable steel, ensuring a strong and reliable structure for heavy-duty operations.
Q: Is the Big Joe LPT33 new?
A: Yes, the LPT33 is a brand-new model, featuring the latest lithium battery technology for high efficiency and reduced downtime.
Maintenance Tips
-
Battery Maintenance – Regularly monitor the lithium battery charge and ensure the terminals are clean and free from corrosion. Keep connections secure and check for any battery faults.
-
Forks and Wheels Inspection – Examine the forks for any cracks or damage and ensure the wheels are free of debris. Clean and lubricate the wheels periodically to ensure smooth movement.
-
Hydraulic System Check – Inspect the hydraulic system for any leaks, ensuring the lift mechanism works smoothly. Top up the hydraulic fluid if necessary.
-
Regular Cleaning – Clean the pallet truck regularly with mild detergent and water, avoiding harsh chemicals that could damage the finish or electrical components.
-
Brakes and Controls Check – Test the brakes and controls before use to ensure proper functionality. Inspect for any issues and address them promptly.
-
Routine Safety Checks – Conduct regular checks on the overall condition of the truck, including battery, lifting system, and structural components, to ensure safety and efficiency during operation.
