Hitachi LP-AW3001 Laser WXGA Ultra Short Throw Projector - LPAW3001
The Hitachi LP-AW3001 3300 Lumens WXGA Ultra-Short Throw 3LCD Projector has the ability to project large images in tight spaces. It produces 3300 lumens of brightness along with a 500,000:1 contrast ratio. This 3LCD system has a WXGA 1280 x 800 native resolution and a long life of up to 20,000 hours. You can use this projector to project up to a 130" image with a 0.3:1 ultra-short throw ratio.
- WXGA Resolution (1280 x 800)
- 20,000 Hours Laser Lamp Life
Specifications
| Custom Aspect Ratio |
16:10 (WXGA) |
| Native Resolution |
1280 x 800 |
| Contrast Ratio |
500,000:1 |
| Throw Distance |
1.3 - 2.8 ft. |
| Lens |
Manual, Fixed 0.30:1 |
| Display Technology |
LCD |
| Wireless Networking |
Yes (Optional Accessory Needed) |
| Speakers |
16W Mono |
| Eco Mode |
50,000 Hours |
| Audible Noise |
28 dB (Normal), 30 dB (Bright Mode) |
| Lamp Life |
20,000 hrs |
| Short Throw |
Yes |
| Aspect Ratio |
16:10 (WXGA) |
| Image Size Diagonal |
59.9 - 130.2 in. |
| Lens Shift |
No |
| Digital Keystone |
Horizontal & Vertical |
| Unit Weight |
16.3 lbs |
| Projector Methods |
Front, Rear, Ceiling |
| Dimensions (WxDxH) |
19.9 x 16.7 x 5.5 in. |
| Power Consumption |
- |
What Our Experts Think
-
Ultra Short-Throw Design – Projects a 100-inch image from just inches away, eliminating shadows and glare.
-
Bright & Vivid Projection – 3,300 lumens and WXGA resolution (1280x800) ensure sharp, clear visuals.
-
Laser Light Source – 20,000-hour lifespan, reducing maintenance and eliminating lamp replacements.
-
3LCD Technology – Delivers accurate colors and smooth motion, ideal for business and education settings.
-
Versatile Connectivity – Equipped with HDMI, VGA, USB, and LAN ports, plus optional wireless functionality for seamless integration.
-
Eco-Friendly & Low Maintenance – Mercury-free laser technology with low power consumption for sustainable operation.
Q&A
Q: What is the Hitachi LP-AW3001 Laser WXGA Ultra Short-Throw Projector?
A: The Hitachi LP-AW3001 is a laser-powered ultra short-throw 3LCD projector designed for classrooms, conference rooms, and interactive presentations. It offers WXGA (1280x800) resolution, 3,300 lumens brightness, and a long-lasting laser light source for maintenance-free operation.
Q: What are the benefits of an ultra short-throw projector?
A: It projects large images from a very short distance, minimizing shadows and glare, making it ideal for tight spaces and interactive environments.
Q: How long does the laser light source last?
A: The laser light source lasts up to 20,000 hours, eliminating the need for lamp replacements and reducing maintenance costs.
Q: Does it support wireless connectivity?
A: Yes, with an optional wireless adapter, it allows wireless presentations for seamless collaboration.
Maintenance Tips
-
Clean the Lens Regularly: Use a microfiber cloth to remove dust and smudges. Avoid abrasive materials and harsh chemicals.
-
Ensure Proper Ventilation: Keep air vents clear and periodically clean filters to prevent overheating.
-
Update Firmware: Check for and install firmware updates to optimize performance and compatibility.
-
Use a Surge Protector: Protect the projector from power fluctuations by connecting it to a stable power source.
-
Store in a Suitable Environment: Avoid excessive heat, humidity, and direct sunlight to extend its lifespan.
-
Handle with Care: Avoid sudden movements, impacts, or tilting during use to prevent internal damage.
-
Power Down Properly: Follow the correct shutdown procedure to maintain the laser light source’s longevity.
