Robopac Semi-Automatic Box Taper Machine, Low Boxes, Fixed Format - Robotape 50 ME LH
The Robopac Wrapman STH is a powerful and user-friendly portable manual pallet wrapping machine designed to secure your palletized goods efficiently and cost-effectively, even in confined spaces. This versatile stretch wrapper ensures optimal protection for your products, reducing damage during transit and storage. Whether you're managing a small warehouse or need a mobile solution for larger operations, the Wrapman STH delivers reliable performance and unmatched portability.
Compact and mobile, the Wrapman STH boasts a small footprint and lightweight design, making it easy to maneuver around your warehouse and eliminating the need for dedicated wrapping stations. Its ability to operate comfortably in areas with limited space makes it perfect for flexible on-demand wrapping needs. The effortless film control allows you to adjust film tension manually using the handle on the carriage, ensuring optimal securing force without complex mechanisms. Simple height adjustment is achieved through electric motor-powered controls, enabling tailored wrapping of various pallet heights. Additionally, the integrated film cutting and parking brake streamline your process, enhancing safety and convenience.
Features
TAPING HEAD 50 ME LHÂ - A taping head for 25 mm and 38 mm width tape is available.
MOTORIZED SIDE BELT CONVEYORS ME LHÂ - The motorized side gripping belt conveyors ensure a constant mesh on the products.
MANUAL ADJUSTMENT OF DIMENSIONSÂ - You can adjust manually height and width of conveyors.
Specifications
| Height conveyor belt |
30mm |
| Infeed speed |
22 m/min |
| Tape width |
25 - 38 mm |
| Minimum boxes dimensions (LxWxH) |
100x80x50mm |
| Maximum boxes dimensions (LxWxH) |
∞x500x500mm |
| Minimum box weight |
1kg |
| Max box weight |
50 kg |
| Power supply voltage |
230 V 1Ph + T - V |
| Power supply frequency |
50 Hz |
| Installed power |
0,4 kW |
What Our Experts Think
-
Low box design – Optimized for sealing shorter box heights.
-
Fixed format – Ideal for operations with consistent box dimensions.
-
Semi-automatic efficiency – Speeds up workflow while reducing manual labor.
-
Robust build – Built for continuous use in industrial environments.
Q&A
Q: Is it suitable for low-height boxes only?
A: Yes, it’s specifically designed for shorter cartons in fixed sizes.
Q: Can it connect to a conveyor line?
A: Yes, it integrates easily with most conveyor systems.
Maintenance Tips
-
Inspect and clean tape head regularly.
-
Check belts and rollers for wear weekly.
-
Lubricate moving parts per manufacturer’s schedule.
-
Disconnect power before performing maintenance.
